Ex ec op is IIC T4 Gc Ex tb op is IIC T70°C or T80°C Db |
  |
Download |
| Data sheet | |
| Manual | |
| Photometry | |
| ATEX certificate | |
| IECEx certificate | |
| EU Declaration |
|
Explosion proof light fitting with LED modules, special optics and ATEX certificate. Designed to use in zones 21 & 2,22 of gas and steam of flammables liquids, as well as combustible dusts and fibers explosion hazard areas. |
Technical data
| TECHNICAL DATA: | Light source: | LED modules | PHOTOMETRY | ||
| Protection class: | I |
|
|||
| IK: | 10 | ||||
| Protection degree: | IP66, IP67 | ||||
| CRI: | >80 | ||||
| Power factor: | >0,97 | ||||
| Long lifetime: | >70 000 hours L80B10 | ||||
| Colour temperature: | 4000K | ||||
| Ambient temperature: | od -40°C do +50°C | ||||
| IK: | 10 | ||||
| BUDOWA: | Housing: | stainless steel | |||
| Diffuser: | polycarbonate UV stabilized | ||||
| Mounting tray: | galvanized steel sheet, powder painted | ||||
| Clamps: | stainless steel | ||||
| MOUNTING: | Light fitting for direct installation with use of brackets. | ||||
| ELECTRICAL UNIT: | Voltage: | 230V, 0/50-60Hz | |||
| Terminal block: | 3x2,5 mm2 (L, PE, N) or 5x2.5 mm2 (L1, L2, L3, PE, N) | ||||
| CERTIFICATES: | KDB 15ATEX0049X | IECEx KDB 20.0003X | |||
